MIKROTIK RouterBOARD mAP lite + L4 (650MHz, 64MB RAM, 1x LAN, 1x 2,4GHz 802.11n) RBmAPL-2nD

tabulka datové propustnosti




Specifications

Details

Product code
RBmAPL-2nD

Architecture
MIPSBE

CPU
QCA9533

CPU core count
1

CPU nominal frequency
650 MHz

Dimensions
48x49x11mm

License level
4

Operating System
RouterOS

Size of RAM
64 MB

Storage size
16 MB

Storage type
FLASH

Tested ambient temperature
-30°C to 70°C


Powering

Details

MicroUSB input Voltage
5-5 V

PoE in
802.3af/at

PoE in input Voltage
10-60 V

Number of DC inputs
2 (PoE-IN, MicroUSB)

Max power consumption
3.5 W


Wireless

Details

Wireless 2.4 GHz number of chains
2

Wireless 2.4 GHz Max data rate
300 Mbit/s

Wireless 2.4 GHz standards
802.11b/g/n

Antenna gain dBi for 2.4 GHz
1.5

Wireless 2.4 GHz chip model
QCA9533


Ethernet

Details

10/100 Ethernet ports
1


Wireless specifications

2.4 GHz
Transmit (dBm)
Receive Sensitivity

1MBit/s
22
-96

11MBit/s
2
